Dettagli:
Termini di pagamento e spedizione:
|
| Power: | AC220V 50Hz | Usage: | Universal Testing Machine |
|---|---|---|---|
| Weight: | 90kg | Product name: | Computer control single column universal testing machine |
| Power supply: | can be customized | Application: | universal tester |
| Standard: | BS.EN.ASTM | Motor: | Panasonic Servo Motor |
| Warranty: | 1 Year | Accuracy: | +/-0.5% |
| Name: | electronic universal testing machine | Capacity: | 20 |
| Stroke: | 650mm(excluding clamp) | Resolution: | 1/250 |
| Tester resolution: | constant the resolution | Operation: | Computer windows operation |
Uses
This machine is designed for quick and reliable tensile, compression, bending, shear, peel, loop tack and fatigue cycling on metals, tape, composites, alloys, rigid plastics and films, elastomers, textiles, paper, board and finished products.
Character
Have steady performace, high accuracy, and easy operation.
Accessories
1.Suitable Grips that meet customer sample need.
2.Special peeling tools for peel test in tape&film industry.
3.English operation teach video.
Specifications
| Design Standards |
ASTM D903,GB/T2790/2791/2792,CNS11888,JIS-K6854,PSTC7
|
| Model |
KJ-1065C
|
| Capacity | 1,2,5,10,20,50,100,200kg optional |
| Stroke | 650mm |
|
Range of speed |
50～400mm/min adjustable,constant speed, 300mm/min |
| Test space | 120mmMAX |
| Accuracy |
±1.0%
|
| Resolution | 1/50,000 |
| Motor | adjustable speed motor |
| Display | force and elongation display |
| Dimention | (W×D×H)50×50×120cm |
| Optional accessories | stretcher, air clamp |
| Weight | 60kg |
| Power | 1PH, AC220V, 50/60Hz |
